Microwave Tube Expansion Furnace

microwave expansion furnace can reach Quick heating rate: max 500C per second; clean energy, controlled atmosphere; laboratory scale and pilot-scale are avaiable since 2015;

We're here to help:

Easy ways to get the answers you need.

Share With:

Watch On:

Technical Data
Product introduction
Comments

Microwave heating offers numerous advantages in productivity over

Conventional heating methods such as hot air,resistive heating,etc. Microwave

Energy penetrates to generate heat internally as well as at the surface of the treated

material. Other methods apply heat only to the surface and temperature must be

Limited in order to avoid burning. Conventional processing time is slow due to

Thermal conductivity. Microwave energy overcomes those time and temperature

Limitations and produces a very high quality product even when the materials being

Processed are fairly thick.

■ Main product

■ Inquiry

postmaster@langfengmetallic.comTel:+86-731-84874716

Name
Country
Address
Phone
E-mail*
Message*	I agree with the privacy terms

	Item	LF-EX1000-1
●	Voltage	220±10V 50Hz
●	Rated Power	5KW
●	Microwave Power	0.01~2.80kW Continuous Adjustable
●	Microwave Frequency	2.45GHz
●	Ultimate Temperature	1000℃
●	Heating Space	Dia 100x Width 150mm
●	Temperature Measured By	thermocouple
●	Temperature Control Range	0~1300℃
●	Temperature Control Accuracy	readout±0.5%
●	Control System	40-stored programmable segments for precision control; data storage;export data；Manual mode, Auto-Mode,constant temperature control, display real - time data curve; dynamic data screen
●	Microwave Leakage	＜0.5mW/cm2
●	Microwave Leakage Detect	Portable Microwave Leakage Detector
●	Feeding and discharge	/
●	Alarm	over heating and over current alarming
●	Exterior Size	630x530x480mm (LXWXH)
●	Control Cabinet	900x500x700mm (LXWXH)
●	Output	500-1000g per day
